Challenger Lifts CL10AV3 Versymmetric Adjustable Two Post Lift

In Stock SKU CL10AV3

OUR PRICE: $7,290.92

Regular Price: $7,659.00

$202.52 / mo
INCLUDES FREE SHIPPING*
asedeals.com widget logo

Short Description

Challenger Lifts CL10AV3-2 Versymmetric Adjustable Two Post Lift
10,000 lbs. Capacity DirectSPOT 3-Stage Front & 3-Stage Rear Arms
3 Adjustable Widths and 2 Adjustable Heights
The Challenger Lifts CL10AV3-2 Versymmetric Adjustable Two Post Lift is designed with versatility and convenience in mind, offering three adjustable widths and two adjustable heights to suit the unique needs of your garage or shop. Featuring Versymmetic Technology, these innovative lifts allow you to service the broadest range of vehicles, significantly enhancing your shop's capability and, most importantly, your bottom line. With it's 3-stage front and rear arms equipped with the pioneering directSPOT design, the days of shuffling a vehicle back and forth to position the front arms properly are over. Now, you can achieve accurate first-try spotting every time, reducing frustration in your shop and skyrocketing your productivity. Challenger Lifts CL10AV3-2 is ALI and ETL Certified. As of 04/21/25, the CL10AV3-2 features a new Bucher Power Unit which will only require a 20 Amp Breaker. Scroll down for more details.

Color Selection:
Textured Red, Textured Blue, and Textured Black

-EV Package Upgrade:
Includes (4) 3" Adapters, (4) 6" Adapters, (4) Organizer Racks, (4) EV Footpads

Made In USA

Description

Challenger Lifts

Challenger Lifts CL10AV3 Versymmetric Adjustable Two Post Lift
10,000 lbs. Capacity DirectSPOT 3-Stage Front & 3-Stage Rear Arms
3 Adjustable Widths and 2 Adjustable Heights

The Challenger Lifts CL10AV3 Versymmetric Adjustable Two Post Lift is designed with versatility and convenience in mind, offering three adjustable widths and two adjustable heights to suit the unique needs of your garage or shop. Featuring Versymmetic Technology, these innovative lifts allow you to service the broadest range of vehicles, significantly enhancing your shop's capability and, most importantly, your bottom line. With it's 3-stage front and rear arms equipped with the pioneering directSPOT design, the days of shuffling a vehicle back and forth to position the front arms properly are over. Now, you can achieve accurate first-try spotting every time, reducing frustration in your shop and skyrocketing your productivity. Challenger Lifts CL10AV3 is ALI and ETL Certified.

In today's fast-paced automotive service industry, efficiency and versatility are paramount. That's where our CL10AV3 model, featuring our exclusive Versymmetric technology, truly shines. This innovative technology allows you to service the broadest range of vehicles, significantly enhancing your shop's capability and, most importantly, your bottom line. With its 3-stage front and rear arms equipped with the pioneering directSPOT design, the days of shuffling a vehicle back and forth to position the front arm properly are over. Now, you can achieve accurate first-try spotting every time, skyrocketing your productivity.

The CL10AV3 comes in various configurations tailored to meet your specific service needs. For shops prioritizing speed, our drive-on pad option ensures the quickest vehicle spotting, ideal for express service lanes. Meanwhile, our QuickCycle upgrade redefines efficiency, boasting an astonishing lift speed - rising in just 27 seconds and descending in 17 seconds. This impressive speed propels your service capabilities to new heights and allows your team to handle more vehicles, enhancing customer satisfaction and your shop's reputation.

Understanding that one size does not fit all, we've made adjustable height and width options, ensuring the CL10AV3 can adapt to your shop's unique requirements. Furthermore, a wide selection of accessories means that no matter what challenges you face, the CL10AV3 is equipped to tackle them, making it the definitive choice for any forward-thinking shop.

Choose the CL10AV3 and expand your service potential with our most versatile, easy-to-operate lift. Proudly ALI Certified, it's not just an investment in equipment but an investment in your shop's future, promising reliability, safety, and unmatched performance.

CL10AV3 Series comes standard with offset 3-stage front arms allowing them to be stowed in an asymmetric lifting position, rear of the front tires. Unlike many competitor lifts, when the vehicle is driven through, the front arms are capable of directSPOT to the vehicle's lifting point without having to reposition the vehicle or shuffle back and forth to reach its recommended lift points.

CL10AV3 Series 2 post hydraulic auto lifts provide automotive service shops with the right equipment to service the most vehicles on the road in one single auto lift service bay. It's Versymmetric two lifts in one design makes it both a car lift (asymmetric lifting) and a truck lift (symmetric lifting). What's this really mean? Shops do not get caught in a situation where they cannot safely and properly lift a certain vehicle that comes in for service.

  • Three Adjustable Widths: The CL10AV3 allows purchasers to customize the width to fit their specific workspace, providing optimal flexibility
  • Enhanced Technician Workspace: The adjustable widths give technicians more room to work, improving efficiency and comfort
  • Flexible Installation Options: With its adjustable design, the CL10AV3 can be installed in various shop configurations, accommodating different spatial constraints
  • Industry First Two Post Auto Lift with Versymmetric Plus Offset 3-Stage Front Arms + 3-Stage Rear Arms
  • Maximum Arm Sweep, reach and retraction meets the widest range of recommended lifting points
  • Offset Front Arms provides single sweep spotting - no rolling vehicles back and forth to swing front arm clear of front tire.

Other standard features include double telescoping screw pads, heavy-duty pulley and cable equalization system, 48" elongated carriage, rubber door guards, adjustable arm restraint shafts, single point mechanical lock release, and padded overhead shut off.

New Power Unit Service Bulletin
As of 04/21/25, Challenger Lifts will be switching to the Bucher AB-9367-DLH and AB-9858-DLH power units from the current SPX AB-9367 and AB-9858 models. These new Bucher power units will only require a 20 amp breaker. Electrical consumption is becoming more important as customers look to save on electrical installation costs (less breakers) and conserve energy.

Benefits Of The Change:
  • Minimum Breaker Required Reduced from 30 to 20 Amp
  • Optimize Power Consumption
  • By consolidating our 10K and 12K power units, we simplify maintenance procedures and reduce inventory complexity

Features & Specs

Features

  • ALI Certified
  • 10,000 lbs. Lift Capacity
  • Versymmetric Offset Front Arms Provide DirectSPOT To Vehicle Lift Points And Safely Lifts Both Symmetrically And Asymmetrically Within The Same Service Bay Maximizing Service Capabilities And Revenue Potential
  • Oversized 5" Diameter Pulley And Heavy Duty 5/16" Cable Reduces Stress On Equalization System And Increases Cable Life
  • 48" Elongated Carriage Design Increases Lift Life
  • Two Settings For Height Adjustment 13' 2" Or 13' 8"
  • Three Settings For Width Adjustment 11' 6.5" / 12' 0.5" / 12' 6.5"
  • Standard Model Fits 12 Foot Ceiling Height
  • Additional 2 Foot Or 3 Foot Extensions Available
  • Padded Overhead Shut Off System Prevents Vehicle Damage
  • Premium Double Telescoping Screw Pads Adjust To Multiple Heights Minimizing The Need For Adapters
  • Fully Gusseted Base Plate Design Increases Column Rigidity
  • Pulley-Less Jacketed Single-Point Lock Release System Makes For Smoother, Easier Operation And Longer Life
  • Standard Dual Integrated Rubber Door Guards Help Protect Vehicle Panels From Inadvertent Damage
  • Plated Arm Restraints And Arm Pins Inhibit Rust And Provide Long-Lasting Durability
  • Premium Powder Coat Finish Provides Long-Lasting Durability

Specifications

Model Number CL10AV3 CL10AV3-2 CL10AV3-QC CL10A-XP9
Lifting Capacity 10,000 lbs. 10,000 lbs. 10,000 lbs. 9,000 lbs.
Lift Configuration Standard 2' Extensions QuickCycle Drive-On Pads
Lifting Configuration Versymmetric
(Symmetric and
Asymmetric)		 Versymmetric
(Symmetric and
Asymmetric)		 Versymmetric
(Symmetric and
Asymmetric)		 Drive-On Pads
Arms 3-Stage Front
3-Stage Rear		 3-Stage Front
3-Stage Rear		 3-Stage Front
3-Stage Rear		 NA
Rise Height 74.125" 74.125" 74.125" 70"
Overall Height 11' 2" or 11' 8" 13' 2" or 13' 8" 11' 2" or 11' 8" 11' 2" or 11' 8"
Overall Height (Cylinder Extended) 11' 11" 13' 11" 11' 11" 11' 11"
2’ Height Extension Available Yes Included Yes Yes
3’ Height Extension Available Yes Yes Yes Yes
Overall Width 11' 6.5" / 12' .5" / 12' 6.5" 11' 6.5" / 12' .5" / 12' 6.5" 11' 6.5" / 12' .5" / 12' 6.5" 11' 6.5" / 12' .5" / 12' 6.5"
Drive-Thru Clearance 100" / 106" / 112" 100" / 106" / 112" 100" / 106" / 112" 100" / 106" / 112"
Floor to Overhead Switch 10' 8.5" - 11' 2.5" 12' 8.5" - 13' 2.5" 10' 8.5" - 11' 2.5" 10' 8.5" - 11' 2.5"
Front Arm Reach 20" - 42" 20" - 42" 20" - 42" NA
Rear Arm Reach 37.625" - 60" 37.625" - 60" 37.625" - 60" NA
Screw Pad Height 3.875" - 6.125" 3.875" - 6.125" 3.875" - 6.125" NA
Max. Load per Arm 2,500 lbs. 2,500 lbs. 2,500 lbs. 2,500 lbs.
Inside Columns 110" / 116" / 122" 110" / 116" / 122" 110" / 116" / 122" NA
Motor / Voltage 2HP
208v-230v 60Hz 1Ph		 2HP
208v-230v 60Hz 1Ph		 3HP
208v-230v 60Hz 1Ph		 2HP
208v-230v 60Hz 1Ph
Speed of Rise 38 Seconds 38 Seconds 24 Seconds 38 Seconds
Ceiling Height Required 12' 14' 12' 12'
ALI/ETL Certified Yes Yes Yes Yes
Quick Cycle - - Yes -
Colors Available Textured
Red, Blue, Black		 Textured
Red, Blue, Black		 Textured
Red, Blue, Black		 Textured
Red, Blue, Black



Service Bay Specifications

  • Bay Height: 12' Minimum
  • Bay Width: 14' Recommended
  • Bay Depth: 24' Recommended
  • Power: 208v-230v, 1Ph, 20 Amp Breaker
  • Minimum Concrete: 4" Thick, Reinforced, Free From Cracks/Seams, 3500+ PSI and Cured 28+ Days
  • Lift Approximate Weight: 1,835-2,025 lbs.

* Optional 3-phase electrical also available, please specify at time of order.

  • Warranty: (5) Years on Structure, (2) Years on Functional Parts, (1) Year Labor

Challenger Lifts Warranty Statement
Challenger Lifts, Inc. (CLI) lifts are guaranteed to the original owner. CLI shall repair or replace, at CLI option, for the full warranty period those parts that prove upon inspection to be defective and pay for all reasonable costs of transportation and/or labor for replacement of said parts for the warranty period stated below. This warranty shall not apply unless the product is installed, used and maintained according to CLI's specifications set forth in CLI's installation, operation, and maintenance instructions. Use of any unapproved parts or accessories will void your warranty. This limited warranty extends only to the original purchaser and in not transferable. This warranty is valid only if the product has been registered with Challenger lifts.

This warranty does not cover normal maintenance or adjustments, damage or malfunction caused by improper handling, installation, abuse, misuse, negligence, carelessness of operation, or normal wear and tear. In addition, this warranty does not cover equipment when repairs have been attempted or made by anyone other than a CLI authorized service representative.

This warranty is exclusive and is in lieu of all other warranties expressed or implied including any implied warranty of fitness for a particular purpose, which implied warranties are expressly excluded. No employee, agent, representative, dealer or other person or entity is authorized to give any warranties of any nature on behalf of CLI.

The remedies described are exclusive and in no event shall CLI, Inc. be liable for special, consequential or incidental damages for the breach of or delay in performance of the warranty. This warranty shall be governed by the Commonwealth of Kentucky, and shall be subject to the exclusive jurisdiction of the Court in the Commonwealth of Kentucky in the County of Jefferson.

Functional parts are considered the power units, cylinders, sheaves, sheave pins, hoses, hydraulic & pneumatic fittings, cables, adapters, latched, valves, and controls.

Structural parts are considered the carriage, columns, column extensions, overhead beams, arms, cross beams, runways, wheel stops, ramps, bolsters., sync rails, and plungers.

Note: Warranty registration must be completed online at challengerlifts.com/register-your-lift or warranty period will begin from invoice date of lift purchase.

Accessories/Options

More Information

Challenger Lifts CL10AV3 Adjustable Two Post Lift Brochure (.pdf)

Challenger Lifts CL10AV3 Adjustable Two Post Lift Manual (.pdf)

Challenger Lifts Anchor Installation Guide (.pdf)

View 2 Post Lift Comparison (.pdf)

View Challenger Lift Guide (.pdf)

Versymmetric Advantage (.pdf)


THE VERSYMMETRIC ADVANTAGE:
Versymmetric auto lifts safely and properly accommodate cars, trucks, crossovers, SUV’s and vans all within the same service bay. Their 2 Lifts in One lift design is perfect for lifting just about any vehicle within lift capacity. The Challenger Versymmetric Plus CL10AV3 automotive lift provides open door clearance to driver controls for both asymmetric lifting applications and symmetric auto lift applications.





So, you want the best? Of course you do!
That's why you're looking at a challenger lift right now.
You know Challenger. They've been around much longer than a strong majority of all those other inferior auto lift manufacturers out there. And it shows. Nobody makes them better. When it comes to their two post lifts, their CL10 Series lifts are the pride of the industry. They boast features that other competitors wish they could offer. Plus, many models are also made in the USA. Contact us for details. When these other manufacturers claim they're just as good as, or the same as a Challenger, don't believe them. There's a reason they have such a long term list of satisfied customers. The cylinders are premium grade and offer ultra-smooth functionality, and they won't start leaking a day after the warranty expires. They were the first manufacturer to offer three stage arms on their top two post lift models, and most models are ALI certified. Many two post models offer the innovative Versymmetric feature invented by Challenger back in 1992 that allows you to adjust the vehicle forward or rearward on the lift, to adjust the center of gravity closer to the columns. This gives you the best of both worlds, so you don't have to choose between symmetric or asymmetric. They are the true pioneers of the industry. Always leading, always innovating, and always providing smart solutions to satisfied auto shop owners.

Challenger Lifts We're Lifting the Toyota Supra
With it's wide body, short wheelbase, and relatively low pad clearance with precise lifting points, special consideration should be made in regards to the lift models that can best accommodate the Toyota Supra.

Why Should you purchase a Challenger Lift from ASEdeals?

1) Guaranteed Lowest Prices - Listen, we monitor our competition's prices. We know we usually have the lowest price on most of our equipment most of the time. Especially since we offer free shipping, while many others do not. In the unlikely event you find any of our automotive lifts advertised anywhere on the web for less, just tell us where you saw them, and we'll beat them. It's that simple. Our prices will not be beaten!

2) One of the Largest Challenger Distributors -This means that you enjoy the benefit of our size. Not only does this allow us to offer the best pricing available, If you have any warranty issues that you feel are not being addressed quickly enough, or to your satisfaction, we have the influence with the manufacturer to get your issue resolved right away.

3) Years of Experience - So many internet companies have popped up over the past few years, claiming to have all kinds of experience, and then when you dig a little deeper, you'll find out that they've only been around for a few years. We've been carrying auto shop equipment for over 20 years now. When you call and speak to us, you're not getting just an order taker that knows nothing about the product. We know these products better than most. Not only will get you answers to your questions, we will make sure that you get the proper lift for your application.

4) Reputation - Right along with the years of experience comes our reputation. Check out our reputation on all of the various car enthusiast forums out there, such as Garage Journal or Corvette Forum. You'll find countless satisfied customers, praising not only our prices, but also our integrity, honesty and ability to help you choose the right product for your application. And then, there's our hundreds of satisfied customer pictures and testimonials to back it up. We'll gladly put our reputation up against anybody's. You can view those testimonials here - //by39tk-uv.myshopify.com/cdn/shop/files/testimonials/  The only way you get this kind of feedback from customers is because they have been dealing with us for 20 years, and know that they can trust us to treat the customer right, and that we know what we’re doing. You can also take a look at customer reviews at - https://www.shopperapproved.com/reviews/asedeals.com/ You’ll see we are a 5 star rated merchant with over 500 customer reviews. That is the highest rating you can get. These are reviews obtained from Shopper Approved. They are an independent 3rd party company, so we have no way of influencing these reviews in any way.
We'll put our reputation up against anybody's.

Click Here For Customer Two-Post Lift Pictures and Testimonials
